| Hardware | |||||||||
| CPU | Intel JASPER LAKE N5105, 4M Cache, 2.9GHz | ||||||||
| GPU | Intel UHD Graphics 620 | ||||||||
| RAM/ROM | 8GB DDR4L / 128GB NGFF SSD Removeable, Optional 16GB DDR4L | ||||||||
| External Memory | Support TF*1,MAX 128GB | ||||||||
| LCD Display | 10.1 inch 16:10, 1200×1920P, 700 cd/m2 | ||||||||
| Touch Panel | 10 points Capacitive，G+G，Rigidity: above 7H-Anti-scratch, Support 930 active pen | ||||||||
| Camera | Front:5.0MP, Rear: 8.0MP With flashlight | ||||||||
| Battery(Small+Big) | Small Battery:Built in polymer lithium ion battery,Non-Removeable 7.4V/700mAh. 30mins(default 50% volumn，default200nit，play 1080P HD video) +Big Battery:Lithium-ion polymer battery , pluggable, Hot Swap,7.4V/5000mAh.6-7hrs(default 50% volumn,default200nit,play 1080P HD video) | ||||||||
| Speaker | Embedded 8Ω/0.8W waterproof speakerx 1 | ||||||||
| Mic | Sensitivity:-42db, Output resistance:2.2kΩ | ||||||||
| TPM | Built-in TPM2.0 | ||||||||
| G_sensor | Gravity acceleration sensor | ||||||||
| Fingerprint | Built-in ×1 SPI Fingerprint (windows hellow boot login) | ||||||||
| Fan | Built-in ×1 IPX5 | ||||||||
| Data Collection & Networking | |||||||||
| Barcode Scanner | 1D Optional Honeywell N6551; 2D Optional Honeywell N3680/N4680 hardcode(Code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse) | ||||||||
| NFC | Optional NXP100, 13.56MHz, ISO/IEC 14443A/B,ISO/IEC 15693, ISO/IEC 18092 | ||||||||
| BT | BT5.0 (BLE) class1 transmission distance：10m | ||||||||
| WIFI | WIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.8G dual band | ||||||||
| 4G | MeiGlink SLM75-VE, LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 | ||||||||
| GPS | U-blox M8Q ,Support:GPS, Beidou module, glonass. Capture sensitivity: -160 dBm; Cool Start Time:less 50second,Hot Start Time:less 28second | ||||||||
| OS | Windows 10/11 Pro inactivated os(Free), Optiona Home/IOT/LTSC | ||||||||
| Module extension (Note: The following modules are one of five) | |||||||||
| Ethernet interface | 1* RJ45 board,(10/100M/1000M) Ethernet interface (Standard Machine is Including RJ45 Port) | ||||||||
| Serial port | 1* DB9 board | ||||||||
| One-dimension barcode | 1* Honeywell N6551 | ||||||||
| Two-dimension barcode | 1*Honeywell N3680/N4680 hardcode | ||||||||
| USB2.0 | 1*USB2.0 | ||||||||
| I/O Port & Appearance & Package | |||||||||
| I/O Port | HDMI 1.4a mini x 1, USB 3.0 Type-A x 1, Type-c x 1(USB3.0/HDMI/Charging), SIM Card x 1, TF Card x 1, RJ45*1 12pin（USB&Docking charging） x 1, Φ3.5mm standard earphone jack x 1, Φ5.5mm DC 19V 3.42A DC jack x 1 | ||||||||
| Keys | F KEY=Scanner key,Scanner key x1,No barcode then customizable ((GPIO) Volume adjustment key(+) x 1,Volume adjustment key(-) x1,windows keyx 1,power keyx1 | ||||||||
| Indicator light | Power on is always blue, power off light is off ×1, (Red and Green) Charging red, full of green, red light flashing on low power, not discharging ×1 | ||||||||
| Power Adaptor | AC100V ~ 240V, 19V3.42A/65W Output USA Standard CE approval. UK/EU Standard Optional | ||||||||
| Dimension | 289.9*196.7*27.4mm | ||||||||
| Weight | Device unit: 1150g. 5000mAh battery：250g | ||||||||
| Package | USB cable/OTG cable/Charger 5V 3A/Handstraps/Packing box（Can be customized logo) | ||||||||
| Certificate System & Reliability Design | |||||||||
| IP67/IP65 | IP65 Report:Water Resistance:IP-X5，Dust Resistance:P-6X R a.Inner Nozzle Diameter:6.3mm； b. Water Speed:12.5±0.625L/min； c. Water Pressure:Adjust according to water volumn； d.Central part of water volumn:A round with a diameter of about 40mm at the distance from the nozzle 2.5m. e.Spray time in surface of panele: About 1 min/Square meter； f.Test time:at least 3min； g.Distance between nozzle and panel surface:2.5～3m. After test,there is no water leakage in sample. | ||||||||
| CE NB | YES | ||||||||
| MIL-STD-810G | YES | ||||||||
| Battery | UN38.3，MSDS,IEC62133 | ||||||||
| Drop Height | 1.22m composite wood floors,in operation status | ||||||||
| Operate Temperature | ‘-20 °C to 60 °C | ||||||||
| Store Temperature | ’-30 °C to 70 °C | ||||||||
| Humidity | Humidity: 95% Non-Condensing | ||||||||
